| Part No | Model No | Applicable tube outer diameterφD |
Thread1 (Rc) |
Thread2 (Rc) |
P | A1 | A2 | B | C | H | G | φK | φX | Orifice Diameter |
Weight(g) | Qty per bag |
Qty per box |
| 16000361 | OPHF 04M5 | 4 | M5x0.8 | M5x0.8 | 10.4 | 5.5 | 5 | 21.2 | 16 | 8 | 6.5 | 10 | 10 | 2 | 7.8 | 10 | 50 |
| 16000362 | OPHF 0401 | 4 | 1/8 | 1/8 | 10.4 | 8 | 9 | 30.5 | 16 | 14 | 9.5 | 14.4 | 10 | 2 | 19.8 | 10 | 50 |
| 16000363 | OPHF 06M5 | 6 | M5x0.8 | M5x0.8 | 12.4 | 5.5 | 5 | 21 | 16 | 8 | 6.5 | 10 | 12 | 2 | 8.5 | 10 | 50 |
| 16000364 | OPHF 0601 | 6 | 1/8 | 1/8 | 12.4 | 8 | 9 | 30.5 | 17 | 14 | 9.5 | 14.4 | 12 | 4 | 20.6 | 10 | 50 |
| 16000365 | OPHF 0602 | 6 | 1/4 | 1/4 | 12.4 | 11 | 12 | 36 | 17 | 17 | 11.5 | 18.4 | 12 | 4 | 33.8 | 10 | 50 |
| 16000366 | OPHF 0801 | 8 | 1/8 | 1/8 | 14.4 | 8 | 9 | 30.5 | 17 | 14 | 9.5 | 14.4 | 14 | 5 | 21.5 | 10 | 50 |
| 16000367 | OPHF 0802 | 8 | 1/4 | 1/4 | 14.4 | 11 | 12 | 36 | 18.5 | 17 | 11.5 | 18.4 | 14 | 5.5 | 35 | 10 | 50 |
| 16000368 | OPHF 0803 | 8 | 3/8 | 3/8 | 14.4 | 12 | 13 | 41.8 | 18.5 | 21 | 13.5 | 22 | 14 | 6 | 59.9 | 5 | 25 |
| 16000369 | OPHF 1002 | 10 | 1/4 | 1/4 | 17.6 | 11 | 13 | 36 | 20 | 17 | 11.5 | 18.4 | 17 | 5.5 | 38 | 5 | 25 |
| 16000370 | OPHF1003 | 10 | 3/8 | 3/8 | 17.6 | 12 | 13 | 41.8 | 20 | 21 | 13.5 | 22 | 17 | 8 | 63 | 5 | 25 |
| 16000371 | OPHF 1203 | 12 | 3/8 | 3/8 | 21 | 12 | 12 | 41.8 | 22.5 | 21 | 13.5 | 22 | 21 | 9 | 66 | 5 | 20 |
| 16000372 | OPHF 1204 | 12 | 1/2 | 1/2 | 21 | 15 | 15 | 51 | 22.5 | 24 | 17 | 28 | 21 | 9 | 99.2 | 5 | 20 |
