| Part No | Model No |
Thread (R1xR2) |
L | φD1 | φD1 | Qty per Iner box |
Qty per outer box |
| 04101801 | VRS-0201 | 1/4x1/8 | 25 | 19 | 16 | 80 | 320 |
| 04101802 | VRS-0301 | 3/8x1/8 | 28 | 22 | 19 | 40 | 160 |
| 04101803 | VRS-0302 | 3/8x1/4 | 28 | 22 | 16 | 40 | 160 |
| 04101804 | VRS-0401 | 1/2x1/8 | 34 | 26 | 16 | 20 | 80 |
| 04101805 | VRS-0402 | 1/2x1/4 | 34 | 26 | 19 | 20 | 80 |
| 04101806 | VRS-0403 | 1/2x3/8 | 34 | 26 | 22 | 20 | 80 |
| 04101807 | VRS-0601 | 3/4x1/8 | 38 | 32 | 16 | 30 | 80 |
| 04101808 | VRS-0602 | 3/4x1/4 | 38 | 32 | 16 | 30 | 120 |
| 04101809 | VRS-0603 | 3/4x3/8 | 38 | 32 | 22 | 30 | 120 |
| 041018010 | VRS-0604 | 3/4xx1/2 | 38 | 32 | 16 | 30 | 120 |
| 041018011 | VRS-0802 | 1"x1/4 | 42 | 39 | 19 | 20 | 80 |
| 041018012 | VRS-0803 | 1"x3/8 | 42 | 39 | 22 | 20 | 80 |
| 041018013 | VRS-0804 | 1"x1/2 | 42 | 39 | 26 | 20 | 80 |
| 041018014 | VRS-0806 | 1"x3/4 | 42 | 39 | 32 | 20 | 80 |
| 041018015 | VRS-1003 | 1"1/4×3/8 | 48 | 48 | 22 | 12 | 48 |
| 041018016 | VRS-1004 | 1"1/4×1/2 | 48 | 48 | 26 | 12 | 48 |
| 041018017 | VRS-1006 | 1"1/4×3/4 | 48 | 48 | 32 | 12 | 48 |
| 041018018 | VRS-1008 | 1"1/4×1" | 48 | 48 | 39 | 12 | 48 |
| 041018019 | VRS-1204 | 1"1/2×1/2 | 52 | 55 | 26 | 10 | 40 |
| 041018020 | VRS-1206 | 1"1/2×3/4 | 52 | 55 | 32 | 10 | 40 |
| 041018021 | VRS-1208 | 1"1/2×1" | 52 | 55 | 39 | 10 | 40 |
| 041018022 | VRS-1210 | 1"1/2×1"1/4 | 52 | 55 | 48 | 10 | 40 |
| 041018023 | VRS-1606 | 2"×3/4 | 58 | 67 | 32 | - | 12 |
| 041018024 | VRS-1608 | 2"×1" | 58 | 67 | 39 | - | 12 |
| 041018025 | VRS-1610 | 2"×1"1/4 | 58 | 67 | 48 | - | 12 |
| 041018026 | VRS-1612 | 2"×1"1/2 | 58 | 67 | 55 | - | 12 |
