Reduced Bore Ball Valve equivalent of Type 600 Body316 SUS316
  • Reduced Bore Ball Valve equivalent of Type 600 Body316 SUS316

Reduced Bore Ball Valve equivalent of Type 600 Body316 SUS316

Tổng quan

Part No Model No

Thread
(Rp)

 φD L H E
01100101 V03-02 1/4 5 39 32.5 61.5
01100102 V03-03 3/8 7 44 36.5 71.5
01100103 V03-04 1/2 9.2 56.5 41.5 87
01100104 V03-06 3/4 12.5 59 44.5 87
01100105 V03-08 1" 15 71 48 103
01100106 V03-10 1"1/4 20 78 54.5 103
01100107 V03-12 1"1/2 25 83 65 126.5
01100108 V03-16 2" 32 100 71.5 126.5
