LTM 1030-2.1 Mobile crane

Tổng quan

LTM 1030-2.1 - The best-selling mobile crane in the world.

The LTM 1030-2.1 mobile crane, which was launched in 1997 with the name LTM 1030/2, was the first mobile crane in the world to feature data bus transfer technology. This innovative technology enabled the 2-axle crane to achieve major enhancements in terms of the functionality and reliability of mobile cranes. On the basis of this crane, the LTM 1030-2.1 has undergone a series of revisions and now represents the state of the art of mobile crane technology. Well over 2500 of these 2-axle cranes have been built. That makes it the best-selling mobile crane in the world and the most successful crane model in the history of all-terrain mobile cranes.









What's inside

  • Up, up and away:

    The integral double folding jib delivers a hoist height of up to 144 ft / 44 m.

  • Time-tested engineering:

    The 4-piece telescopic boom can be extended quickly using the time-tested hydro-mechanical telescoping system.

  • Lower fuel consumption:

    ECOmode reduces fuel consumption by up to 10%.

  • Up to date:

    This was the first crane to have data bus technology and today features lots of modifications to keep it state of the art.

  • A great view:

    Fast, safe set-up process for the crane using BTT remote control. Optional BTT-E remote control means that the crane can be controlled in a direct line of sight whilst in action.

Technical data

Max. load capacity 40 US t
at radius 10 ft
Telescopic boom from 30 ft
Telescopic boom up to 98 ft
Lattice jib from 28 ft
Lattice jib up to 49 ft
Drive engine/make Cummins
Drive engine 6-Zylinder-Diesel
Drive engine/power 280 hp
Number of axles 2
Drive/Steering standard 4 x 4 x 4
Driving speed 53.00 mph
Total ballast 12,100 lb



Downloads

Technical Data - Mobile crane LTM 1030-2.1 [ft/lb]
