FA/FB (3 phase) Hook suspension:
- Tough, heavy-duty motor.
FA : 3-phase single speed type
FB : 3-phase dual speed type
SA : 1-phase single speed type - Reliable electro-magnetic DC brake.
- Highly durable load chain of our own manufacture.
- Totally enclosed steel plate construction.
- Wiring: Simple plug-in type connection of wires.
- Overload alarm hook.
In case of overloading, it gradually elongates without fracture. - Chain bucket
specially strengthened plastic bucket - Capacity : 0.5 - 3ton
| Model | FA-0.5 | FA-1 | FA-2 | FA-3 | |
| Max. working load (ton) | 0.5 | 1.0 | 2 | 3 | |
| Manufacturer's test load (ton) | 0.625 | 1.25 | 2.5 | 3.75 | |
| Standard lift (m) | 3 | 3 | 3 | 4 | |
| Standard push button cord length (m) | 2.5 | 2.5 | 2.5 | 3.5 | |
|
Load chain dia x number of falls
|
6.3x1 | 7.1x1 | 7.1x2 | 7.1x3 | |
| Lifting motor output (kw) | 0.9 | 1.6 | 1.6 | 1.6 | |
| Lifting speed (m/min) |
50Hz | 7.0 | 6.3 | 3.1 | 2.1 |
| 60HZ | 8.4 | 7.5 | 3.8 | 2.5 | |
| Headroom (mm) | 555 | 590 | 745 | 840 | |
| Net weight (kg) | 43(46) | 56(60) | 64(71) | 83(90) | |
1)The number bracketed in "Net weight (kg)" indicates 6m lift.
2)The length of power cord is 4 core-0.5m (standard).
| Model | FB-0.5 | FB-1 | FB-2 | FB-3 | |
| Max. working load (ton) | 0.5 | 1.0 | 2 | 3 | |
| Manufacturer's test load (ton) | 0.625 | 1.25 | 2.5 | 3.75 | |
| Standard lift (m) | 3 | 3 | 3 | 4 | |
| Standard push button cord length (m) | 2.5 | 2.5 | 2.5 | 3.5 | |
|
Load chain dia x number of falls |
6.3x1 | 7.1x1 | 7.1x2 | 7.1x3 | |
| Lifting motor output (kw), (FB) High:Low speed |
0.9:0.25 | 1.6:0.4 | 1.6:0.4 | 1.6:0.4 | |
| Lifting speed(m/min) (FB) High:Low speed |
50Hz | 7.0:1.8 | 6.3:1.6 | 3.1:0.8 | 2.1:0.5 |
| 60HZ | 8.4:2.1 | 7.5:1.9 | 3.8:0.9 | 2.5:0.6 | |
| Headroom (mm) | 555 | 590 | 745 | 840 | |
| Net weight (kg) | 44(47) | 57(61) | 65(72) | 84(91) | |
| 1)The number bracketed in "Net weight (kg)" indicates 6m lift. |
| 2)The length of power cord is 4 core-0.5m (standard). |
